ASTA Type Test

Test	Type Test - 3200A
Standards	IEC 61439 - 1& 2
Resistance to corrosion	Severity test A
Mechanical impact	IK 08
Mechanical operation	200 operations
Degree of protection of enclosures	IP4X, Form 4b
Clearances & Creepage distances	Minimum allowable clearance : 8mm Minimum allowable creepage : 12.5mm
Protection against electric shock and integrity of protective circuits	30kA rms 1s, 63kA peak
Power frequency withstand voltage	Ui =1000 V for complete assembly
Impulse withstand voltage	Uimp =8 kV for complete assembly
Short circuit withstand strength	Icw: 50kA 1 Sec for complete assembly Ipk: 105kA
Temperature Rise Limits	3200A
